"YOUNG "- Heavy duty Sand Mix-Muller are specially designed, sturdy constructions and easy maintenance. Best Quality and tested raw materials are used and hence long life ensured even at high working rate. Means fit it forget it.
SCRAPERS: Two scraper are provided for combined mixing and aerating action. One aerating the sand the periphery of the pan and the other around the center block. These scrapers are so arranged that sand is continually through in the path of rollers which ensure through mixing & mulling
Muller: Muller are made of heavy weight and having more width. The special design of eliminate the possibility of jamming.
Mixer: Special design of mixing arm helps to mix quickly. Usually the plate of mixing arm needs often replacement. Due to special design replacement of plate becomes very easy.
Bearing: Right type and size of bearing and use of more number of bearing in cover the life of machine and consume less power.
Gear & Electrical: electrical motor and gears are totally enclosed by covers. Enclosed mechanism protect against accidents and also reduce the vibration and notice. Self lubricating gears are reduce the maintenance cost down time and increase the life of gears and bearings.
Most useful for FOUNDRY ABRASIVE POWDER CERAMIC FERTILIZER COLOUR DETERGENT REFRACTORY MINERALS FOOD PAINT AND MASALA industries etc.
| Batch Capacity (Approx.) |
Ele. Motor H.P. |
Muller Size Dia. × W. |
R.P.M. Of Muller (Approx.) |
Dia. Of Pan m.m. - ft. (Approx.) |
|---|---|---|---|---|
| 25 KG. | 2.0 H.P. | 10" × 5" | 24-28 | 750-2.5' |
| 75 KG. | 3.0 H.P. | 12" × 6" | 24-28 | 900-3' |
| 150 KG. | 5.0 H.P. | 16" × 8" | 24-28 | 1200-4' |
| 250 KG. | 7.5 H.P. | 18" × 9" | 24-28 | 1500-5' |
| 300 KG. | 10.0 H.P. | 18" × 9" | 24-28 | 1500-5' |
| 500 KG. | 20.0 H.P. | 20" × 10" | 24-28 | 1650-5.5' |
| 750 KG. | 25.0 H.P. | 20" × 10" | 24-28 | 1800-6' |
| 1000 KG. | 30.0 H.P. | 24" × 12" | 24-28 | 1800-6' |
| 2000 KG. | 50.0 H.P. | 24" × 12" | 24-28 | 2100-7' |
| 3000 KG. | 75.0 H.P. | 27" × 18" | 24-28 | 2900-8' |
| 4000 KG. | 100.0 H.P. | 30" × 18" | 24-28 | 2700-9' |
| 5000 KG. | 150.0 H.P. | 36" × 21" | 24-28 | 3000-10' |
